NANOTEC PD4-C - 3225 H Analogue Inputs Switches

9 Description of the object dictionary
Description
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
AC2 AC1
In general: If a bit is set to the value "0", the analog input measures the voltage; if the bit is set to the value
"1", the current is measured.
AC1
Setting for analog input 1
AC2
Setting for analog input 2
3225h Analogue Inputs Switches
Function
This object contains the position of the DIP switches . The switch position is only read during a restart one
time.
Object description
Index 3225
h
Object name Analogue Inputs Switches
Object Code ARRAY
Data type UNSIGNED16
Savable no
Access read only
PDO mapping no
Allowed values
Preset value
Firmware version FIR-v1436
Change history
Firmware version FIR-v1436: "PDO mapping" table entry for subindex
01 changed from "RX-PDO" to "TX-PDO".
Value description
Subindex 00
h
Name Highest Sub-index Supported
Data type UNSIGNED8
Access read only
PDO mapping no
Allowed values
Preset value 01
h
Version: 2.0.1 / FIR-v1650 177
