4 Commissioning
4 Commissioning
Described in this chapter is how you establish communication with the controller and set the necessary
parameters to make the motor ready for operation.
The Plug & Drive Studio software offers you an option for performing the configuration and adapting the
motor parameters to your application. You can find further information in document Plug & Drive Studio:
Quick Start Guide at us.nanotec.com.
The controller also offers you the possibility to switch special drive modes on/off via the DIP switch. You
can thereby control the motor directly via the inputs (analog input/clock-direction). See chapter Special drive
modes (clock-direction and analog speed) for details.
Observe the following notes:
CAUTION
!
Moving parts can cause hand injuries.
If you touch moving parts during running operation, hand injuries may result.
►
Do not reach for moving parts during operation. After switching off, wait until all movements
have ended.
CAUTION
!
In free-standing operation, motor movements are uncontrolled and can cause injuries.
If the motor is unsecured, it can, e.g., fall down. Foot injuries or damage to the motor could occur.
►
If you operate the motor free-standing, observe the motor, switch it off immediately in the event
of danger and make certain that the motor cannot fall down.
CAUTION
!
Moving parts can catch hair and loose clothing.
During running operation, moving parts can catch hair or loose clothing, which may lead to injuries.
►
If you have long hair, wear a hairnet or take other suitable protective measures when near
moving parts. Do not work with loose clothing or ties near moving parts.
CAUTION
!
Risk of overheating or fire if there is insufficient cooling!
If cooling is insufficient or if the ambient temperature is too high, there is a risk of overheating or fire.
►
During use, make certain that the cooling and environmental conditions are ensured.
