NANOTEC PD4-C - 3322 H Analogue Input Pre-Scaling

9 Description of the object dictionary
Allowed values
Preset value 02
h
Subindex 01
h
Name Analogue Input 1
Data type INTEGER32
Access read / write
PDO mapping no
Allowed values
Preset value 00000000
h
Subindex 02
h
Name Analogue Input 2
Data type INTEGER32
Access read / write
PDO mapping no
Allowed values
Preset value 00000000
h
Description
●
Subindex 00
h
: Number of offsets
●
Subindex 01
h
: Offset for analog input 1
●
Subindex 02
h
: Offset for analog input 2
3322h Analogue Input Pre-scaling
Function
Value by which the read analog value (3320
h
, 3321
h
) is divided before it is written in object 3320
h
.
Object description
Index 3322
h
Object name Analogue Input Pre-scaling
Object Code ARRAY
Data type INTEGER32
Savable yes, category: application
Firmware version FIR-v1426
Change history
Value description
Subindex 00
h
Name Number Of Analogue Inputs
Data type UNSIGNED8
Access read only
Version: 2.0.1 / FIR-v1650 191
