7 Special functions
Number
dec hex Signal source
00 00 Signal is always 0
01 01 Physical input 1
02 02 Physical input 2
03 03 Physical input 3
04 04 Physical input 4
05 05 Physical input 5
06 06 Physical input 6
07 07 Physical input 7
08 08 Physical input 8
09 09 Physical input 9
10 0A Physical input 10
11 0B Physical input 11
12 0C Physical input 12
13 0D Physical input 13
14 0E Physical input 14
15 0F Physical input 15
16 10 Physical input 16
65 41 Hall input "U"
66 42 Hall input "V"
67 43 Hall input "W"
68 44 Encoder input "A"
69 45 Encoder input "B"
70 46 Encoder input "Index"
71 47 USB Power Signal
73 49 DIP switch 1
74 4A DIP switch 2
75 4B DIP switch 3
76 4C DIP switch 4
77 4D DIP switch 5
78 4E DIP switch 6
79 4F DIP switch 7
80 50 DIP switch 8
The following table describes the inverted signals of the previous table.
Number
dec hex Signal source
128 80 Signal is always 1
129 81 Inverted physical input 1
130 82 Inverted physical input 2
131 83 Inverted physical input 3
132 84 Inverted physical input 4
133 85 Inverted physical input 5
134 86 Inverted physical input 6
Version: 2.0.1 / FIR-v1650 82
