Trainee Guide TR-L2-M2000
Level 2 Maintenance Training - M2000 Dispensing Systems 2-2-77 P/N 73-0018-00 (Revision B)
Diagram Sheet 2-10-1
Heating Elements and Temperature Controllers
Heating
Element
Thumbscrew
Power Cable
J-Type
Thermocouple
Cable
HT-04
HT-06
O
O
O
O
O
O
O
O
Control Panel
Close-up
On/Off Switch
HT-2000 Temperature Controller
HT-1000 Temperature Controller
HT-10N
