Trainee Guide TR-L2-M2000
Level 2 Maintenance Training - M2000 Dispensing Systems 2-2-79 P/N 73-0018-00 (Revision B)
Diagram Sheet 2-10-2
Needle Heater Connections (not to scale)
Microcontrolle
r
120/220 VAC From
AC Power Source
J-Thermocouple
or RTD
DC Power
Dispense
Head
DC Powe
r
J-Thermocouple
or RTD
Needle
Heate
r
