Trainee Guide TR-L2-M2000
Level 2 Maintenance Training - M2000 Dispensing Systems 2-2-92 P/N 73-0018-00 (Revision B)
Diagram Sheet 2-12-1
Common Conveyor Configuration (Contact Heaters)
Part Sensor
Stop Pin
Stop Pin
Part
Sensor
Lift Table
(Underneath
Heater Plates)
