Nordson Asymtek M-2000

Trainee Guide TR-L2-M2000
Level 2 Maintenance Training - M2000 Dispensing Systems 3-2-11 P/N 73-0018-00 (Revision B)
Diagram Sheet 3-3-2
Leveling the Scale
Cut-out Showing Scale Leveling
Screw (one screw on the
underside of each corner)
Scale Base
Scale Leveling Screws
Close-up of
Scale Level
Scale Base
Purge
Station
Weigh
Station
Scale Level Location
