Trainee Guide TR-L2-M2000
Level 2 Maintenance Training - M2000 Dispensing Systems 3-2-27 P/N 73-0018-00 (Revision B)
Diagram Sheet 3-6-2
DP-3000 Chamber Assembly
High Pressure Chamber Assembly
Black O-Ring
Urethane O-Ring
Priming Chamber
Metal Luer
Prime Port
Pumping Chamber
Seal (insert ring-side
down)
Pumping
Chamber
Priming O-Ring
Priming Chamber
Static O-Ring
Pumping
Chamber Seal
(insert ring-side
down)
Pumping
Chamber
Plastic Prime Port
Standard Chamber Assembly
