Trainee Guide TR-L2-M2000
Level 2 Maintenance Training - M2000 Dispensing Systems 3-2-33 P/N 73-0018-00 (Revision B)
Diagram Sheet 3-6-5
DV-6000 – Disassembled
Valve Motor
Check Valve
(
o
p
tional
)
Needle
Amp Connector
Feedscrew
(
DO NOT REMOVE
)
Teflon Seal
Luer Elbow
Stainless Steel
Luer Lock Fittin
g
Black Shield
Lower Luer Lock
(
DO NOT REMOVE
)
Motor Mount
Cleats
