Trainee Guide TR-L2-M2000
Level 2 Maintenance Training – M2000 Dispensing Systems 3-2-43 P/N 73-0018-00 (Revision B)
15
10
5
Diagram Sheet 3-6-10
DJ-2000
Micrometer
Assembly
Upper
Body
Syringe
Luer Lock
Purge
Screw
Lower
Body
Heater
Extension
Preload
Bracke
t
RTD
Cable
Solenoid
Connector
Nozzle
Black
Pneumatic
Hose
Heater
Cable
Height
Sensor
Preloa
d
Scre
w
Outer
Micrometer
Collar
Micromete
r
Lock Nu
t
3-mm Bolts
