Trainee Guide TR-L2-M2000
Level 2 Maintenance Training – M2000 Dispensing Systems 1-2-2 P/N 73-0018-00 (Revision B)
Information Sheet 1-1-1
Basic Platform and Optional Modular Components
A. System Description
1. The M-2000 Series dispensing system is designed primarily for Advanced
Semiconductor Package Assembly (ASPA) and Printed Circuit Board Assembly (PCBA)
applications.
2. The system platform can, however be configured for various applications.
B. Basic Platform
1. Fluidmove for Windows
®
or Fluidmove for Windows NT
®.
2. Needle Sensor
3. Vision System
4. Purge Stations
5. Belt Conveyor
C. Optional Modular Components
1. Weigh station with scale for mass flow calibration
2. Needle Heater
3. 4 channel temperature controller (for the Needle Heater)
4. Underboard supports
5. NER
®
dual on-axis lighting
