Trainee Guide TR-L2-M2000
Level 2 Maintenance Training – M2000 Dispensing Systems 4-2-72 P/N 73-0018-00 (Revision B)
Information Sheet 4-16-2
PMAC Plot (Continued)
C. Plotting Data
1. Open the PMAC Plot Program.
 Press [Ctrl]-ESC
 Select Programs, Pmac Plot, PmacPlot.
2. Click on the Quick Plot tab.
3. Click on Motors to Gather.
 Select motors (commanded and actual) to be analyzed.
 1 = x-motor, 2 = y-motor, 3 = z-motor.
- The fewer motors selected, the greater the sampling of data.
 Set gather period long enough to gather motions being analyzed.
4. Select choices of axis to be plotted.
 Select first choice and click on Add to Left or Add to Right.
 Repeat with second choice.
5. Click on Define Gather Buffer.
 This must be repeated each time prior to running a dispensing program.
 It clears the gather buffer.
6. Press [Alt]-Tab to return to FmNT.
7. Run the program.
8. Press [Alt]-Tab to return to PMAC Plot.
9. Click on Upload Data.
10. Click on Plot Data.
11. Plot
 Maximize Window.
 Click far right button, Change Pmacplot Option (See Diagram Sheet 4-16-2
on page 4-2-73).
 Select Scale.
 Select Left or Right Vertical Axis that has the following error set value:
- Minimum: -20
- Maximum: 20
- Fixed: 5
12. If time needs to be zoomed in, select Scale, Horizontal Axis and set values.
13. Click OK.
To Next Page
