The components of the scanner (optional)
NOTE
The scanner calibration sheet for the [Océ Scanner Express] is located in the media drawer, at
the back of roll 2.
The components of the scanner
Component Description / Function
1 [scanner top cover] Closes off the scanner.
2 [original feeding table] Use the [original feeding table] to feed the origi-
nal into the scanner (face up).
3 [scanner open levers] Use the [scanner open levers] to open the [scan-
ner top cover].
4 [originals exit] Exit for the scanned original.
5 [Output refeed protector] Prevents that your output is not refed into the
scanner.
The components of the scanner (optional)
Chapter 2 - Get to Know the Printing System
33
