Oce PlotWave 360 Operation Guide

The folder (optional)
Introduction
The printer can be delivered with an external folder. The Océ PlotWave 340 is compatible with the
Océ 2400 fanfold. The Océ PlotWave 360 is compatible with the Océ 2400 fanfold and the Océ
4311 fullfold.
NOTE
• A technician is required to install the folder and configure the system.
• For more information on folders, visit
http://downloads.oce.com/ and select your product.
Media compatibility with the folder
Media name Compatible with the folder
Paper 60 g Yes
[Paper 64 g] Yes
[Paper 75 g] Yes
[Paper 75-80 g] Yes
[Recycled pap. 80 g] Yes
[Paper 90-110 g] Yes
NOTE
For folding speed reasons, outputs longer than 1.2m must be printed one sheet at a time.
The folder (optional)
36
Chapter 2 - Get to Know the Printing System

Oce PlotWave 360 Specifications

General

Print Technology	Océ Radiant Fusing technology
Resolution	600 x 1200 dpi
Maximum Media Width	36 inches
Print Speed	6 A1/D prints per minute
Media Handling	2 rolls
Warm-up Time	Instant On
Weight	195 kg
Media Width	Up to 36 inches
