Oce PlotWave 360 Operation Guide

Océ ClearConnect: the multi-touch user panel
Introduction to Océ ClearConnect
Introduction
The Océ ClearConnect is a multi-touch user panel, with dynamic tiles for print, copy, and scan
jobs.
The Océ ClearConnect
1
4
2
3
5
6
Component Function
1. [status light] Light that gives feedback on the status of the printer.
• A green light indicates that the printer is ready.
• A green blinking light indicates that the printer is busy.
• A red light indicates that an error occurred.
2. [wake-up button] The button that allows the operator to do the following:
• Get the printer out of sleep mode.
• Wake the printer up to full functionality.
3. [USB port] You can insert a USB mass storage device to:
• Print a file directly from the USB mass storage device.
• Scan an original and save it directly on the USB device.
The green light that illuminates the port starts to blink during data
transfer.
4. [stop button] The button with a red light that allows the operator to do the following:
• Immediately interrupt a scan job.
• Stop a print job after the page that is being printed.
5. [home button] The button that allows the operator to do the following:
• Return to the home screen on the user panel display.
• Reset settings to default, by pressing the button twice.
4
Océ ClearConnect: the multi-touch user panel
38
Chapter 2 - Get to Know the Printing System

Oce PlotWave 360 Specifications

General

Print Technology	Océ Radiant Fusing technology
Resolution	600 x 1200 dpi
Maximum Media Width	36 inches
Print Speed	6 A1/D prints per minute
Media Handling	2 rolls
Warm-up Time	Instant On
Weight	195 kg
Media Width	Up to 36 inches
