Parker 590+ series - Block 3

Serial Communications A-21
DC590+ Series DC Digital Drive
Block 3
PNO (ID) (MN) TAG DATA FORMAT LIMITS ACCESS DESCRIPTION
BINARY ASCII BIT ASCII BINARY MIN TO MAX
24 18 030 21 xxx.xx -200.00/200.00 R/W Additional Current Demand
25 19 015 21 xxx.xx 0/200.00 R/W Main Current Limit
26 1A 087 21 xxx.xx 0/200.00 R/O +ve Current Clamp
27 1B 088 21 xxx.xx 0/200.00 R/O -ve Current Clamp
28 1C 016 21 xxx.xx 0/200.00 R/W Current Loop P Gain
29 1D 017 21 xxx.xx 0/200.00 R/W Current Loop I Gain
30 1E 171 21 xxx.xx 0/100.00 R/W Field Current Setpoint
31 1F 116 23 xxxxx R/O Health Store
0 0/1 Over Speed
1 0/1 Missing Pulse
2 0/1 Field Over Current
3 0/1 Fin Over Temperature
4 0/1 Motor Over Temperature
5 0/1 Field Over Volts
6 0/1 Speed Feedback
7 0/1 Encoder Fail
8 0/1 Field Fail
9 0/1 Three Phase
10 0/1 Phase Lock Loop
11 0/1 5703 Receive Error
12 0/1 Stall Trip
13 0/1 Over Current Trip
14 0/1 Cal. Card
15 0/1 ACCTS Failed.
