Parker 590+ series User Manual

D-110 Programming
DC590+ Series DC Digital Drive
SELECT
Used to select a value from one of eight inputs,
depending on the value of the select input. A second
output is provided to allow the block to be used as
two banks of four inputs.
SELECT
Parameter
Tag
Range
INPUT 0 to INPUT 7 1156 to 1163 -32768.00 to 32768.00
Inputs to the select block
SELECT 1164 0 to 7
Determines which of the inputs is routed to OUTPUT 1 . In addition, if SELECT INPUT is in the range 0 to 3, INPUT 4 to INPUT 7 respectively is
routed to OUTPUT 2, otherwise OUTPUT 2 is unchanged.
OUTPUT 0 1165

.xx
Selected output
OUTPUT 1 1166

.xx
Alternative selected output from INPUT 4 to INPUT 7 if SELECT is less than 4.

Parker 590+ series Specifications

General

Control Mode	Speed, Torque, Position
Operating Temperature	0°C to 40°C
Altitude	Up to 1000 m without derating
Speed Regulation	0.01% of base speed
Communication Options	Ethernet, Profibus, CANbus, Modbus, DeviceNet
Feedback Options	Tachometer, Encoder
Protection Rating	IP20
Storage Temperature	-25°C to 55°C
Relative Humidity	5% to 95% (non-condensing)
