Parker 590+ series User Manual

Technical Specifications E-31
DC590+ Series DC Digital Drive
Termination Tightening Torque (Frame 6)
Description Fixings Spanner Size Format Torque Nm
ACCT central bolt M12 19mm Bolts 45Nm (33 ft/lbf)
Fishplate fixings for A+, A-, L1, L2, L3 M10 17mm Nut insert 55Nm (40.6 ft/lbf)
Phase Assembly Mountings M10 17mm Bolt 32Nm (23.6 ft/lbf)
Control Panel Assembly (support screws) M6 10mm Screw 4.5Nm (3.3 ft/lbf)
Fuse Assembly to Mounting Plate M12 19mm Bolt 45Nm (33 ft/lbf)
Fuse Assembly/Mounting Plate to Phase Assembly M10 17mm Bolt 32Nm (23.6 ft/lbf)
Termination Tightening Torque (Frame H)
Description Fixings Spanner Size Format Torque Nm
Drive Mounting Fixings M12 19mm Bolt 57.2
Ground studs on back panel M10 17mm Nut 32.8 (24.3 ft/lbf)
Fuse assy to Phase assy M10 17mm Bolt 24
AC Input & DC Output Bus bars M12 19mm Nut & Bolt 57.2
Fuse assembly M12 19mm Bolt 42 (31 ft/lbf)
Fuse assembly to CT M12 19mm Bolt 42 (31 ft/lbf)
DC Output terminal panel to side panel M6 10mm Bolt 6.8
DC Bus bars M6 10mm Nut 6.8
I/P terminal assy M6 10mm Nut 4
Lifting Bracket Fixings M10 17mm Bolt 24

Parker 590+ series Specifications

General

Control Mode	Speed, Torque, Position
Operating Temperature	0°C to 40°C
Altitude	Up to 1000 m without derating
Speed Regulation	0.01% of base speed
Communication Options	Ethernet, Profibus, CANbus, Modbus, DeviceNet
Feedback Options	Tachometer, Encoder
Protection Rating	IP20
Storage Temperature	-25°C to 55°C
Relative Humidity	5% to 95% (non-condensing)
