Parker 590+ series User Manual

D-72 Programming
DC590+ Series DC Digital Drive
LINK
Use internal links to connect between function block parameters.
LINK
Parameter
Tag
Range
LINK 1 - 80
SOURCE TAG Refer to Parameter Table -1276 to 1276
Enter the tag number of the source input value. Refer to “Making and Breaking Function Block Connections”, page D-2.
DESTINATION TAG Refer to Parameter Table 0 to 1276
Enter the tag number for the destination output value. Refer to “Making and Breaking Function Block Connections”, page D-2.

Parker 590+ series Specifications

General

Control Mode	Speed, Torque, Position
Operating Temperature	0°C to 40°C
Altitude	Up to 1000 m without derating
Speed Regulation	0.01% of base speed
Communication Options	Ethernet, Profibus, CANbus, Modbus, DeviceNet
Feedback Options	Tachometer, Encoder
Protection Rating	IP20
Storage Temperature	-25°C to 55°C
Relative Humidity	5% to 95% (non-condensing)
