E-32 Technical Specifications
DC590+ Series DC Digital Drive
Cooling Fans
Output Current
(armature)
(A)
Maximum
Rating Ambient
(°C)
Cooling Method Number of Fans Fan Power Rating
110/120V ac
Fan Power Rating
220/240V ac
Frame 1
15 45 no fan N/A N/A N/A
35 45 Integral Fan (24V dc) 1 (internal) N/A N/A
Frame 2
40 45 Integral Fan (24V dc) 1 (internal) N/A N/A
70 45 Integral Fan (2 x 24V dc) 2 (internal) N/A N/A
110 45 Integral Fan (24V dc) 1 (internal) N/A N/A
165 45 Integral Fan (2 x 24V dc) 2 (internal) N/A N/A
Frame 3
180 45 Forced Vent 120cfm (200m³/hr) @ 60Pa 1 (internal) 40W, 50/60Hz 45/39W, 50/60Hz
270 45 Forced Vent 120cfm (200m³/hr) @ 60Pa 1 (internal) 40W, 50/60Hz 45/39W, 50/60Hz
Frame 4
380 40 Forced Vent 240cfm (410m³/hr) @ 200Pa 1 (internal) 130W, 10μF 140W, 2.5μF
500 40 Forced Vent 240cfm (410m³/hr) @ 200Pa 1 (internal) 130W, 10μF 140W, 2.5μF
725 40 Forced Vent 240cfm (410m³/hr) @ 200Pa 1 (internal) 130W, 10μF 140W, 2.5μF
830 40 Forced Vent 240cfm (410m³/hr) @ 200Pa 1 (internal) 130W, 10μF 140W, 2.5μF
Frame 5
1580 40 Forced Vent 240cfm (410m³/hr) @ 200Pa 2 (internal) 130W, 10μF (each fan) 140W, 2.5μF
(each fan)
Frame 6
All ratings 40 Integral Fan (6 x 24V dc) 6 (internal) 48W See note below 48W See note below
Frame H
1200 40 Separate Fan 2 (external) See note below See note below
1700 40 Separate Fan 2 (external) See note below See note below
2200 40 Separate Fan 2 (external) See note below See note below
2700 40 Separate Fan 2 (external) See note below See note below
Fans supplied with Frame 6 units have an air flow rate of 215cfm per fan (2 per phase assembly, 6 in total)
Fan SMPS:
115V ±10%, 3A, 300W or 230V ±10%, 1.5A, 300W Assembly Part Number LA466819
Fans supplied with Frame H units have an air flow rate per fan of 850m³/hr at 250 Pascal
Fan Ratings:
115V ac 50Hz, 1.67A, 177W, 2750 rpm, motor run capacitor 18F
115V ac 60Hz, 2.21A, 240W, 2660 rpm, motor run capacitor 18F
