Parameter Specification Tables C-1
DC590+ Series DC Digital Drive
Parameter Tables
The headings for the Tag No. table are described below.
Tag A numeric identification of the parameter. It is used to identify the source and destinations of internal links.
Mn Serial Communications Mnemonic:
Refer to Appendix A: “Serial Communications”
MMI Block Name The menu page under which the parameter is stored on the MMI.
MMI Parameter Name The parameter name as it appears on the MMI.
Minimum/Maximum/
Default/Units/Range
The Range varies with parameter type:
INT The upper and lower limits of the parameter, indicating the parameter’s true, internally-held, number of
decimal.
Note:
Decimal Places - some internally held parameters with two decimal places are only displayed
with one decimal place. These parameters are indicated in the Parameter Description tables. The
Range parameter highlights these with “(h)”.
BOOL 0 = FALSE, 1 = TRUE
WORD 0x0000 to 0xFFFF (hexadecimal)
Output parameters are not saved in non-vol memory unless noted otherwise.
Input parameters are saved in non-vol memory unless noted otherwise.
Notes
View levels:
V0 Normal
V1 Advanced
Write qualifiers:
W0 Always
W1 Only when stopped
W2 Only when in configuration mode
W3 Only in thee-button reset mode
W4 Read only, (output parameters)
Parameter Types:
Parameters that look like 0x0000 are WORDS
Parameters that have text are BOOLs if they have a range of 0,1
Parameters that have text are WORDS if their range is 0 to greater than 1
All other parameters are INT (integers)
If a parameter can only be written to in Config mode, this implies that the drive is stopped.
