Parker 590+ series - Acceleration;Deceleration Rates

Programming D-107
DC590+ Series DC Digital Drive
t
RAMP INPUT (+ 100%)
0%
+100%
RAMP OUTPUT
RAMP ACCEL TIME
(S RAMP 0%)
RAMP DECEL TIME
(S RAMP 0%)
ACTUAL ACCEL TIME
WITH S RAMP
ACTUAL DECEL TIME
WITH S RAMP
t
0%
t
t
0%
0%
RAMP OUTPUT
-100%
RAMP INPUT (-100%)
RAMP ACCEL TIME
(S RAMP 0%)
RAMP DECEL TIME
(S RAMP 0%)
ACTUAL ACCEL TIME
WITH S RAMP
ACTUAL DECEL TIME
WITH S RAMP
ACCELERATION/DECELERATION RATES
