E-8 Technical Specifications
DC590+ Series DC Digital Drive
Power Supply Details
3-Phase
Supply
LV Build All Frames
110-220V ac ±10%, 50/60Hz 5%, line-to-line, ground referenced (TN) and non-ground referenced (IT)
MV Build(standard) All Frames
220-500V ac ±10%, 50/60Hz 5%, line-to-line, ground referenced (TN) and non-ground referenced (IT)
HV Build Frame 4
Frame 5
500-600V ac ±10%, 50/60Hz 5%, line-to-line, ground referenced (TN) and non-ground referenced (IT)
Frame 6 & H
500-690V ac ±10%, 50/60Hz 5%, line-to-line, ground referenced (TN) and non-ground referenced (IT)
Supply Current (0.9 x Idc) Amps ac rms
Field Supply Current (1 x Idc) Amps ac rms (build related)
Field Supply Voltage Build-related
3 Phase Input 3-phase rotation insensitive, no adjustment necessary for frequency change
Auxiliary Power Supply Details
Auxiliary Supply
Auxiliary Supply Current
110-230V ±10%, 50-60Hz 10%, single phase, Overvoltage Category II
Where auxiliary cooling fans are used, then the supply is set by the requirement for the fan, i.e. 115V ±10% or 230V ±10%. Refer to
Model Number, page E-E-1.
3A ac rms maximum. Nominal current used for power supplies: 0.5A at 115V ac, 0.25A at 230V ac
Fan current for integral fans: refer to
Cooling Fans, page E-32. The remainder is available for driving the AC Contactor
Frame 6: Total of 3A ac maximum, 250W.
Contactor Output 3A maximum at the auxiliary voltage
