E-16 Technical Specifications
DC590+ Series DC Digital Drive
Terminal Definitions (Digital/Analog Inputs & Outputs)
User inputs are IEC1131 compliant. Terminal blocks A, B, and C are located on the control board each block being a 9 way plug-in connector. In
addition to terminal blocks A, B and C, terminal blocks G and H provide connections when the two option modules are fitted on the control board.
Digital Input Rated Voltage:
• Off Region
• Transition Region
• On Region
Input Impedance
Sample Interval
Debounce Period
Encoder Mode (Digital Input 1 & 2):
• SPACE Region
• Transition Region
• MARK Region
Maximum Clock Frequency
24V dc
-3V to +5V, min.current not defined, max. 15mA
+5V to +15V, min.0.5mA, max. 15mA
+15V to +30V, min. 2mA, max. 15mA
Nominally 3.3k
5ms
3ms
5V logic
-3V to +0.5V
+0.5V to +3V
+3V to +30V
100kHz
Digital Output
These outputs are active high and
source current from the terminal to
the load. Thus the load must be
connected between the output and
the signal ground. A free-wheel
diode is included in the output to
protect the output transistor when
switching inductive loads such as
relays.
Digital Output Voltage
Output Update Interval
Output Impedance
Source/Sink
Rated Current
Temporary Overload
Overload Protection
Overload Recover
Reverse Voltage Protection
Operating Voltage
Off state leakage current
Nominally +24V dc
5ms
Negligible up to 50mA load
Source
+100mA maximum source
None
Indefinite short circuit protection provided
Automatic
Protected against current-limited reverse voltage sources (<100mA)
<30V dc
<0.4mA sourcing
Analog Input
Input Resolution
Input Impedance
Input Impedance Limit
Sample Interval
Hardware Latency
Overload Capability
12 Bit plus sign, i.e. 2.5mV resolution, equals 0.025% of full scale deflection
112k
10k (signal range -10V to +10V)
5ms, and just-in-time for control loops on Analog I/P 2 (A3), min. 5ms
1.3ms filter for Analog I/P (A3) and 2.5ms for others.
+10%, i.e. maximum recognisable voltage +/-11V. Analog Tachogenerator input
should be applied to Terminal G3 on Calibration Option Card only.
