Parker 590+ series User Manual

E-30 Technical Specifications
DC590+ Series DC Digital Drive
Wire Sizes and Termination Tightening Torques (Frames 1-5)
• Power cables must have a minimum rating of 1.1 x full load current - EUROPE
• Control wiring must have a minimum cross-section area of 0.75mm
2
(18AWG)
UL EUROPE
Terminations
Maximum Tightening
Torque
Recommended Wire Size
Maximum Terminal
Aperture Size (AWG)
Maximum Terminal Aperture Size (mm
2
)
165A UNITS
A+, A- 42.4Nm (375 lb-in) 4/0 AWG 250 cmil 120
L1, L2, L3 5.6Nm (50 lb-in) 1/0 AWG 2/0 70
Grounding terminal 5.6Nm (50 lb-in) 3 AWG 2/0 70
F+, F- 0.8Nm (7.0 lb-in) 14 AWG 12 2.5
L, N, 3, 4, TH1, TH2 0.5Nm (5.0 lb-in) 12 AWG 12 2.5
Frame 3
180A, 270A UNITS
A+, A- 11Nm (97 lb-in) 2/0 AWG - -
L1, L2, L3 11Nm (97 lb-in) 2/0 AWG - -
Grounding terminal 6.8Nm (60 lb-in) 2/0 AWG - -
D1- D8 0.45Nm (4.0 lb-in) 14 AWG - -
THERM+, THERM- 0.45Nm (4.0 lb-in) 14 AWG - -
Frame 4 & 5 380A, 500A, 725A, 830A, 1580A UNITS
A+, A- 23Nm (204 lb-in) - -
L1, L2, L3 23Nm (204 lb-in) - -
Grounding terminal 6.8Nm (60 lb-in) - -
FL1, FL2 0.8Nm (7 lb-in) - -
F+, F- 0.8Nm (7 lb-in) - -
Auxiliary supply, contactor
and motor thermistor
0.6Nm (5 lb-in) - -

Parker 590+ series Specifications

General

Control Mode	Speed, Torque, Position
Operating Temperature	0°C to 40°C
Altitude	Up to 1000 m without derating
Speed Regulation	0.01% of base speed
Communication Options	Ethernet, Profibus, CANbus, Modbus, DeviceNet
Feedback Options	Tachometer, Encoder
Protection Rating	IP20
Storage Temperature	-25°C to 55°C
Relative Humidity	5% to 95% (non-condensing)
