Parker 590+ series User Manual

D-134 Programming
DC590+ Series DC Digital Drive
TEC OPTION
Parameter
Tag
Range
TEC OPTION FAULT 506 See below
The fault state of the Technology Option.
0 : NONE no faults
1 : PARAMETER parameter out-of-range
2 : TYPE MISMATCH TYPE parameter mismatch
3 : SELF TEST hardware fault - internal
4 : HARDWARE hardware fault - external
5 : MISSING no option fitted
If the VERSION NUMBER error message is displayed, the Technology Option is using software that doesn’t fully support the drive; refer to Parker
SSD Drives.
TEC OPTION VER 507 0x0000 to 0xFFFF
The version of the Technology Option. If no option is fitted then the version is reset to zero.
TEC OPTION OUT 1 to TEC OPTION OUT 2 508, 509

.
The use of these output parameters depends upon the type of Technology Option fitted. Refer to the Technology Option Technical Manual.

Parker 590+ series Specifications

General

Control Mode	Speed, Torque, Position
Operating Temperature	0°C to 40°C
Altitude	Up to 1000 m without derating
Speed Regulation	0.01% of base speed
Communication Options	Ethernet, Profibus, CANbus, Modbus, DeviceNet
Feedback Options	Tachometer, Encoder
Protection Rating	IP20
Storage Temperature	-25°C to 55°C
Relative Humidity	5% to 95% (non-condensing)
