8-28 Ethernet
AC30 series Variable Speed Inverters
Parameter Name No. Path Default Range Units Writable
A diagnostic parameter indicating the state of the internal PTP state machine.
Enumerated values:
0: NONE the PTP module is disabled or the Ethernet cables are removed
1: INITIALISNG the PTP is initialising the data sets and communications
2: FAULTY the PTP module failed to initialise
3: DISABLED the PTP will not send any messages and will accept only PTP management messages
4: LISTENING the PTP is listening for Announce messages from a master or waiting to timeout on received
announce messages.
5: PRE-MASTER
the PTP behaves as though it were in the MASTER state but will not send any messages except
for peer delay, signalling or management messages.
6: MASTER the PTP is behaving as a master
7: PASSIVE the PTP will not send any messages except for peer delay, signalling or management messages
8: UNCALIBRATED
the PTP is in a transient state.
One or more master ports have been detected in the domain. The
appropriate master port has been selected, and the local port is preparing to synchronize to the
selected master port.
9: SLAVE the PTP is synchronizing or synchronized to a master
9
Monitor::Communications::P
TP Parameters::Base
Comms::PTP
00:00:00
Diagnostic parameter giving the current value of the PTP clock to 1 second accuracy. Note this is not
intended to represent the actual date and time.
