Page #113 background imageLoading...
Page #113 background image
Ethernet 8-29
AC30 series Variable Speed Inverters
Parameter Name No. Path Default Range Units Writable
PTP Offset
168
7
Monitor::Communications::P
TP
Parameters::Base
Comms::PTP
0 ns -2000000000 to
2000000000
NEVER
PTP parameter.
Diagnostic parameter giving the average offset in nanoseconds between the PTP clock and the master
clock.
PTP Locked
168
8
Monitor::Communications::P
TP Parameters::Base
Comms::PTP
FALSE FALSE
TRUE
NEVER
PTP parameter.
Diagnostic parameter indicating when the inverter is a slave that the PTP clock has synchronised to a
master clock determined by parameter 1685 PTP Locked Threshold. If the inverter is a master then this
parameter will be set to TRUE.
