Parker AC30 series User Manual

Fire Mode 9-5
AC30 series Variable Speed Drive
ID
Trip Name
Disabled in Partial mode
Disabled in Full mode
Drive Protection
26
OVERSPEED
 
27
SAFE TORQUE OFF
 
28
FEEDBACK MISSING
 
29
INTERNAL FAN FAIL
 
30
CURRENT SENSOR
 
31
POWER LOSS STOP
 
32
SPEED SENSOR FAULT
 
33
A1
 
34
A2
 
35
A3
 
36
A4
 
37
A5
 
38
A6
 
39
A7
 
40
A8
 
41
SPEED ERROR FAULT
 
42
PEER TO PEER OVERRUN
 
43
PHASE CONFIG
 
44
ETHERNET IP BREAK
 
45
RESOLVER ERROR
 
46
PMAC ALIGN ERROR
 
47
CURRENT IMBALANCE
 
48
CONFIGURATION
 
Note 1. The Under Voltage trip is enabled when Fire Mode is active, but the trip level is reduced by 50%.
If a trip source becomes active when the associated trip is disabled the drive will continue to run. This is also the normal behavior of the drive,
(when Fire Mode is not active). If the associated trip is designed for drive protection, this will be recorded in non-volatile memory. The recorded
values are available to view in the Trips History parameter block, (refer to Appendix C).
When Fire Mode is activated and a trip source becomes active and the associated trip is enabled, the drive will trip, causing the motor to stop.
This is similar to the normal behavior of the drive, (when Fire Mode is not active). However, when Fire Mode is active the drive firmware
continues to monitor the trip source, once the trip source has become inactive the drive automatically resets the trip condition and restarts the
drive.
The Fly catching feature can be used to allow the drive to smoothly resume control of a moving load on restart.
The operation of Fire Mode is independent of the motor type motor and the control mode, (Open Loop or Sensorless Vector control).
