Parker AC30 series User Manual

C-202 Parameter Reference
AC30 series Variable Speed Drive
Parameter Name
No.
Path
Default
Range
Units
Writable
Monitor
1270
Parameters::Device Manager::Soft
Menus
ALWAYS
An array of PNOs that identifies the parameters to be shown in the Monitor menu
Functional Description
The Soft Menus group of parameters are used to populate the associated menus depending on the associated application, (Control Screen, Setup
and Monitor) or the requirements of the location, (Favourites). The contents of the Setup and Monitor menus may only be set by the application itself.
The contents of the Favourites menu may be set by writing to the parameters in the Favourites array. Alternatively parameters may be added to or
removed from the Favourites menu by use of the GKP. Navigate to the parameter of interest and hold the OK key until the attributes screen is
shown. If the parameter is not already in the Favourites menu a pressing Soft Key 2 adds the parameter to Favourites. This operation is indicated by
the icon . Similarly, to remove a parameter from Favourites, navigate to the parameter in the Favourites menu then press OK until the
parameter attributes are shown. Remove the parameter from Favourites by pressing Soft Key 2. This operation is indicated by the icon .

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
