Parker AC30 series User Manual

Parameter Reference C-235
AC30 series Variable Speed Drive
0038
Digout Value.Relay 12
Monitor::Inputs and Outputs
Parameters::Inputs And Outputs::IO Values
BOOL
FALSE
ALWAYS
OPERATOR
2
00603
0039
Anin 01 Value
Same as PNO 38
REAL
x.x
-100.0 to 100.0
%
NEVER
OPERATOR
00605
0040
Anin 01 Break
Same as PNO 38
BOOL
NEVER
OPERATOR
4
00607
0041
Anin 02 Value
Same as PNO 38
REAL
x.x
-100.0 to 100.0
%
NEVER
OPERATOR
00609
0042
Anout 01 Value
Same as PNO 38
REAL
0.00
Min to Max
%
ALWAYS
OPERATOR
2
00611
0043
Anout 02 Value
Same as PNO 38
REAL
0.00
Min to Max
%
ALWAYS
OPERATOR
2
00613
0044
Comms Required
Setup::Communications::Option
Parameters::Option Comms::Comms
USINT
(enum)
1
1:NONE
2:BACNET IP
3:BACNET MSTP
4:CANOPEN
6:CONTROLNET
7:DEVICENET
8:ETHERCAT
9:ETHERNET IP
10:MODBUS RTU
11:MODBUS TCP
12:PROFIBUS DPV1
13:PROFINET IO
14:PASSIVE SERIAL
15:BC OPTION
CONFIG
TECHNICIAN
00615
0045
Comms Fitted
Monitor::Communications::Option
Parameters::Option Comms::Comms
USINT
(enum)
0:UNKNOWN
1:NONE
2:BACNET IP
3:BACNET MSTP
4:CANOPEN
5:CC LINK
6:CONTROLNET
7:DEVICENET
8:ETHERCAT
9:ETHERNET IP
10:MODBUS RTU
11:MODBUS TCP
12:PROFIBUS DPV1
13:PROFINET IO
14:PASSIVE SERIAL
15:BC OPTION
16:POWERLINK
NEVER
OPERATOR
1
00617
0046
Comms State
Parameters::Option Comms::Comms
USINT
(enum)
0:SETUP
1:NW INIT
2:WAIT PROCESS
3:IDLE
4:PROCESS ACTIVE
5:ERROR
6:RESERVED
7:EXCEPTION
8:NONE
NEVER
ENGINEER
4
00619
0047
Comms Supervised
Same as PNO 45
BOOL
NEVER
OPERATOR
4
00621
0048
Comms Trip Enable
Same as PNO 44
BOOL
TRUE
ALWAYS
TECHNICIAN
4
00623
0049
Comms Module Version
Same as PNO 45
DWORD
NEVER
TECHNICIAN
4
00625
0050
Comms Module Serial
Same as PNO 45
DWORD
NEVER
TECHNICIAN
4
00627
0051
Comms Diagnostic
Same as PNO 45
USINT
(enum)
0:OK
1:HARDWARE MISMATCH
2:INVALID CONFIGURATION
3:MAPPING FAILED
4:EXCEPTION
5:UNSUPPORTED OPTION
NEVER
OPERATOR
00629
0052
Comms Diagnostic Code
Same as PNO 45
DWORD
NEVER
OPERATOR
4
00631
0053
Comms Exception
Same as PNO 45
BYTE
NEVER
TECHNICIAN
4
00633
0054
Comms Net Exception
Same as PNO 45
BYTE
NEVER
TECHNICIAN
4
00635
0055
Read Mapping
Setup::Communications::Option
Parameters::Option Comms::Read Process
ARRAY[0..31]
CONFIG
TECHNICIAN
00637
0056
Read Mapping[0]
Same as PNO 55
UINT
0627
0000 to 3145
CONFIG
TECHNICIAN
4
00639
0057
Read Mapping[1]
Same as PNO 55
UINT
0681
0000 to 3145
CONFIG
TECHNICIAN
4
00641
0058
Read Mapping[2]
Same as PNO 55
UINT
0000
0000 to 3145
CONFIG
TECHNICIAN
4
00643
0059
Read Mapping[3]
Same as PNO 55
UINT
0000
0000 to 3145
CONFIG
TECHNICIAN
4
00645
0060
Read Mapping[4]
Same as PNO 55
UINT
0000
0000 to 3145
CONFIG
TECHNICIAN
4
00647
0061
Read Mapping[5]
Same as PNO 55
UINT
0000
0000 to 3145
CONFIG
TECHNICIAN
4
00649
0062
Read Mapping[6]
Same as PNO 55
UINT
0000
0000 to 3145
CONFIG
TECHNICIAN
4
00651
