Data management

R&S

ZNL/ZNLE

114User Manual 1178.5966.02 ─ 20

Windows Per Page

Defines how many windows are displayed on a single page of the printout. This setting

is only available if Print Multiple Windows is active (see Chapter 6.3.1.1, "Print content

settings", on page 105).

If more than one window is printed on one page, each window is printed in equal size.

Remote command:

HCOPy:PAGE:WINDow:COUNt on page 596

Scaling

Determines the scaling of the windows in the printout if Print Multiple Windows is active

(see Chapter 6.3.1.1, "Print content settings", on page 105).

If more than one window is printed on one page (see Windows Per Page), each win-

dow is printed in equal size.

"Maintain

aspect ratio"

Each window is printed as large as possible while maintaining the

aspect ratio of the original display.

"Size to fit"

Each window is scaled to fit the page size optimally, not regarding the

aspect ratio of the original display.

Remote command:

HCOPy:PAGE:WINDow:SCALe on page 596

Margins

Defines margins for the printout page on which no elements are printed. The margins

are defined according to the selected unit.

Remote command:

HCOPy:PAGE:MARGin:BOTTom on page 594

HCOPy:PAGE:MARGin:LEFT on page 594

HCOPy:PAGE:MARGin:RIGHt on page 594

HCOPy:PAGE:MARGin:TOP on page 595

HCOPy:PAGE:MARGin:UNIT on page 595

6.3.1.5 Print color settings

Access: "Print" > "Print Config" > "Color" tab

Creating screenshots of current measurement results and settings
