VNA GUI reference

R&S

ZNL/ZNLE

483User Manual 1178.5966.02 ─ 20

●

The full n-port calibration types (n > 1, e.g. "TOSM") are symbolized by a closed

square symbol. The number of arrows increases the complexity but can also

improve the accuracy of the calibration.

For an overview, refer to Table 9-7.

Remote command:

[SENSe<Ch>:]CORRection:COLLect:METHod:DEFine

Calibrate all Channels

Check this box to apply the acquired correction data to all channels in the active chan-

nel setup. Leave it unchecked (preset setting) to apply them only to the active channel.

Note that this option is available only if the active channel setup contains multiple

channels.

Remote command:

[SENSe:]CORRection:COLLect:CHANnels:ALL

Proceeds to Step 2: Connectors and Cal Kits.

Step 2: Connectors and Cal Kits

Selects the connector type and gender for all ports and allows you to import a calibra-

tion kit.

Background information

Refer to Chapter 9.5.2, "Calibration standards and calibration kits", on page 255.

Messages in the dialog

An information message (or error message) is displayed if one of the following hap-

pens:

●

One of the selected calibration kits is described by ideal kit parameters or typical

values.

●

One of the selected calibration kits does not contain all standards that are required

for the previously selected calibration type.

●

Different connector types are defined at the ports but the selected calibration type

requires uniform connectors.

●

A cal kit standard does not cover the entire calibrated frequency range.
