Command reference
R&S
®
ZNL/ZNLE
797User Manual 1178.5966.02 ─ 20
Example:
*RST; CALC:LIM:CONT 1 GHZ, 2 GHZ
Define an upper limit line segment in the stimulus range
between 1 GHz and 2 GHz, using default response values.
CALC:LIM:STAT ON; FAIL?
Switch the limit check on and query the result.
CALC:CLIM:FAIL?
Query the result for the composite limit check. As only one trace
is tested, the response should be equal to the previous
response.
Usage: Query only
Manual operation: See "Global Check" on page 434
CALCulate<Chn>:DLINe <Position>
Defines the position (response value) of the horizontal line.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<Position> See list of parameters below.
Default unit: NN
Example:
*RST; :CALC:DLIN 10
Define the position of the horizontal line in the default dB Mag
diagram at +10 dB.
CALC:DLIN:STAT ON
Display the defined horizontal line.
Manual operation: See "Response Value" on page 449
CALCulate<Chn>:DLINe:STATe <Boolean>
Switches the horizontal line on or off.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<Boolean> ON | OFF - horizontal line on or off
*RST: OFF
Example: See CALCulate<Chn>:DLINe
Manual operation: See "Show Horiz. Line" on page 449
CALCulate<Chn>:FORMat <Type>
Defines how the measured result at any sweep point is post-processed and presented
in the graphical display.
