R&S ZNL Series User Manual

Command reference
R&S
®
ZNL/ZNLE
857User Manual 1178.5966.02 ─ 20
Example: Assume that the current channel setup contains a trace named
Trc1.
MMEM:STOR:TRAC 'TRC1', 'C:\Users\Public
\Documents\Rohde-Schwarz\ZNL\Traces\Trc1.s1p'
Store the current trace data of Trc1 to a trace file.
MMEM:LOAD:TRAC 'TRC1', 'C:\Users\Public
\Documents\Rohde-Schwarz\ZNL\Traces\Trc1.s1p'
Load the previously created trace file and create a memory trace
assigned to Trc1.
CALC:PAR:DEF:SGR 1,2
Create four traces to measure the two-port S-parameters S
11
,
S
12
, S
21
, S
22
. The traces are not displayed.
MMEM:STOR:TRAC 'TRC1', 'C:\Users\Public
\Documents\Rohde-Schwarz\ZNL\Traces\Trc1.s2p'
Store the four S-parameter traces to a two-port Touchstone file.
MMEM:LOAD:TRAC 'TRC1', 'C:\Users\Public
\Documents\Rohde-Schwarz\ZNL\Traces\Trc1.s2p'
Load the previously created Touchstone file and overwrite the
previously generated memory trace assigned to Trc1 with the
S
11
trace.
Usage:
Setting only
Manual operation: See "Import Data to New Mem" on page 388
MMEMory:LOAD:TRACe:AUTO <TraceFile>
Loads the specified trace file and automatically distributes the imported S-parameter
traces S
ij
to all diagrams in the active channel that are currently displaying S
ij
.
Setting parameters:
<TraceFile> String parameter to specify the name and directory of the trace
file to be loaded. Several file formats for trace files are suppor-
ted. The file extensions *.s<n>p, *.csv, and *.dat for Touch-
stone, ASCII, and Matlab files are mandatory.
If no path is specified the analyzer searches the current direc-
tory, to be queried with MMEMory:CDIRectory?
Usage: Setting only
Manual operation: See "Auto Distribute" on page 393
MMEMory:LOAD:VNETworks<Ch>:BALanced:DEEMbedding<LogPt>
<TouchstoneFile>[, <Port>[, <Interchange>]]
MMEMory:LOAD:VNETworks<Ch>:BALanced:EMBedding<LogPt>
<TouchstoneFile>[, <Port>[, <Interchange>]]
Loads the S-parameter data that (partly) specify the de-/embedding network of bal-
anced port <LogPt> from local Touchstone files.
VNA command reference
