<TestPort2> Second calibrated port number.
<TestPort3 or
AdapterCalKit>
Either the third calibrated port number, or – for Adapter Removal
calibrations only – the file path (relative to the current directory)
where the analyzer shall store the adapter characterization
obtained during the calibration.
The latter is optional. If a file path is provided, the characteriza-
tion file (in Touchstone s2p format) is generated when the cor-
rection terms are finally calculated ([SENSe<Ch>:
]CORRection:COLLect:SAVE:SELected[:DUMMy]).
<TestPorts> More ports to be calibrated.
Example:
CORRection:COLLect:METHod:DEFine 'Test',RSHort,
1
Select a one-port normalization at port 1 with a short standard
as calibration type.
Manual operation: See "Type/Source" on page 482
The supported calibration types are listed below.
Parameter Type (GUI)
REFL | RSHort Refl Norm Open | Refl Norm Short
FOPort Full One Port ("Refl OSM")
FRTRans | UTRans n-port calibration types "Trans Norm Both" (forward and reverse) |
"Trans Norm" (unidirectional), n > 1
For calibration type UTRans, the VNA performs star-shaped
Through measurements, with <TestPort1> used as the source
port. For calibration type FRTRans, it performs all possible
Through measurements between the specified test ports.
FTRans | RTRans Two-port calibration type "Trans Norm" in "Forward" | "Reverse"
direction, where "Forward" ("Reverse") means that the port with
the smaller (larger) port number is the source port.
OPTPort One Path Two Ports
TOSM TOSM
UOSM UOSM
Not available for R&S ZNL/ZNLE3|4|6 with old VNA board (order
no 1323.0070)
TRL TRL
Not available for R&S ZNL/ZNLE3|4|6 with old VNA board (order
no 1323.0070)
[SENSe<Ch>:]CORRection:COLLect:SAVE:SELected:DEFault
Generates a set of default correction data for the selected ports and calibration type.
The default data set corresponds to a test setup which does not introduce any system-
atic errors; none of the measurement results acquired previously ([SENSe<Ch>:
]CORRection:COLLect[:ACQuire]:SELected) is considered.
