R&S ZNL Series User Manual

Command reference
R&S
®
ZNL/ZNLE
960User Manual 1178.5966.02 ─ 20
[SENSe<Ch>:]SEGMent<Seg>:INSert:SELect <TimeRef>
Defines whether the sweep time of a new segment, i.e. numeric parameter no. 5 of the
command [SENSe<Ch>:]SEGMent<Seg>:INSert, is entered as a segment sweep
time ("Segment Time") or as a measurement delay ("Meas Delay").
Suffix:
<Ch>
.
Channel number
<Seg> Sweep segment number
Parameters:
<TimeRef> SWTime | DWELl
SWTime - use segment sweep time.
DWELl - use measurement delay.
*RST: SWTime
Example:
SEGM1:INS:SEL DWEL
Select the meas. delay to determine the sweep time in a new
sweep segment no. 1.
SEGM1:INS 1MHZ, 1.5MHZ, 111, -21DBM, 0.01S, 0,
10KHZ
Create a sweep segment with a sweep range between 1.0 MHz
and 1.5 MHz and a meas. delay of 10 ms.
SEGM1:SWE:TIME?
Query the sweep time in the new segment.
Manual operation: See "Optional Columns" on page 337
[SENSe<Ch>:]SEGMent<Seg>:POWer[:LEVel] <IntSourcePow>
Defines the power of the internal signal source in sweep segment no. <Seg>. At the
same time, the command activates separate power control in all sweep segments
([SENSe<Ch>:]SEGMent:POWer[:LEVel]:CONTrol).
Suffix:
<Ch>
.
Channel number
<Seg> Sweep segment number
Parameters:
<IntSourcePow> Internal source power
Range: -300 dBm to +200 dBm. The usable power range is
frequency-dependent; refer to the data sheet.
*RST: -10 dBm
Default unit: dBm
Example:
SEGM:ADD
Create a new sweep segment no. 1 in channel no. 1 using
default settings and thus -10 dBm internal source power.
SEGM:POW -20
Decrease the power to -20 dBm.
Manual operation: See "Optional Columns" on page 337
VNA command reference
