R&S ZNL Series User Manual

Command reference
R&S
®
ZNL/ZNLE
963User Manual 1178.5966.02 ─ 20
Parameters:
<Boolean> ON – use independent delay settings, to be defined via
[SENSe<Ch>:]SEGMent<Seg>:SWEep:DWELl.
OFF – reset the delay in all sweep segments to the delay for
unsegmented sweeps, defined via [SENSe<Ch>:]SWEep:
DWELl.
The parameter is automatically switched to ON when a meas.
delay time is entered using [SENSe<Ch>:]SEGMent<Seg>:
SWEep:DWELl.
*RST: OFF
Example:
SEGM:ADD
Create a new sweep segment no. 1 in channel no. 1 using
default settings and thus 0 s meas. delay.
SEGM:SWE:DWELl 0.1
Increase the meas. delay to 0.1 s.
SEGM:SWE:DWELl:CONT OFF
Couple the meas. delay in all segments and reset the delay in
segment no. 1 to the initial value of 0 s.
Manual operation: See "Optional Columns" on page 337
[SENSe<Ch>:]SEGMent<Seg>:SWEep:POINts <SegPoint>
Defines the total number of measurement points in sweep segment no. <Seg>.
Suffix:
<Ch>
.
Channel number
<Seg> Sweep segment number
Parameters:
<SegPoint> Number of points in the segment
Range: 1 to 100001. 1 is allowed if start and stop frequen-
cies are equal.
*RST: 51
Example:
SEGM:ADD
Create a new sweep segment no. 1 in channel no. 1 using
default settings.
SEGM:SWE:POIN 401
Increase the number of points to 401.
Manual operation: See "Table Columns" on page 334
[SENSe<Ch>:]SEGMent<Seg>:SWEep:TIME <SegSweepTime>
Sets the duration of the sweep in sweep segment no. <Seg> ("Segment Time"). At the
same time, the command activates separate sweep time setting in all sweep segments
([SENSe<Ch>:]SEGMent<Seg>:SWEep:TIME:CONTrol ON).
