Data management
R&S
®
ZNL/ZNLE
99User Manual 1178.5966.02 ─ 20
6.2.2.2 Storage location and filename
The data is stored on the internal flash disk or, if selected, on a memory stick or net-
work drive. The operating system, firmware and stored instrument settings are located
on drive C.
The storage location and filename are selected in a file selection dialog box which is
displayed when you perform a storage function.
By default, the name of a settings file consists of a base name followed by an under-
score and three numbers, e.g. limit_lines_005. In the example, the base name is
limit_lines. The base name can contain characters, numbers and underscores.
The file extension dfl is added automatically. The default folder for settings files is
C:\Users\Public\Documents\Rohde-Schwarz\ZNL\Save.
File name restrictions
File names must be compatible with the Windows conventions for file names. In partic-
ular, they must not contain special characters such as ":", "*", "?".
6.2.2.3 Save and recall dialog boxes
Access: "Save"/ "Open" icon in the toolbar > "Save" / "Recall"
Both dialog boxes are very similar and closely related.
Storing and recalling instrument settings and measurement data
