R&S ZVB - Page 1004

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 989
Types
Example:
FREQ:STAR 0.9E+9; STOP 1.1E+9
Set frequency range from 0.9 GHz to 1.1 GHz.
SWEep:POINts 101
Set number of sweep points to 101 resulting in a frequency spacing of 2 MHz.
SOUR:GRO 1,2
SOUR:GRO 3,4
Create two port groups with ports 1 and 2 in port group 1 and ports 3 and 4 in
port group 2.
SOURce:GROup:SIMultaneous:FOFFset:MOFFset:MODE DIRect
Set minimum frequency offset to be specified directly.
SOURce:GROup:SIMultaneous:FOFFset:MOFFSet:DVALue 2 MHz
Set minimum frequency offset to 2 MHz.
SOURce:GROup:SIMultaneous:FOFFset:STATe ON
Activate Simultaneous Measurement with Frequency Offset.
SOURce:GROup:SIMultaneous:FOFFset:CONDition?
// Check the operation mode of Simultaneous Measurement with Frequency
Offset.
SOURce<Ch>:GROup:SIMultaneous:STATe <Boolean>
This command is used to activate/deactivate simultaneous measurement of port groups.
Please note that setting this flag does not change the port group setup.
<Ch>
Channel number.
If unspecified, this parameter is set to 1.
<boolean>
ON | OFF – activates or deactivates simultaneous measurement of port groups
*RST value
ON
Please note that after a factory reset no port groups are defined so that no
simultaneous measurement takes place even though this flag is set to ON.
SCPI,
Command
Types
Device-specific, command or query
Example:
SOURce:GROup:SIMultaneous:STATe OFF
Deactivate the simultaneous measurement of (existing) port groups e.g. to
compare measurement results with and without simultaneous measurement.
SOURce<Ch>:LPORt<log_port> <phys_port1>[,<phys_port2>]
Defines a logical port numbered <log_port>, by either assigning a single physical port <phys_port1>, or
combining two physical ports <phys_port1> and <phys_port2> to form a balanced port.
