TRACe...
This subsystem handles active trace data and trace data stored in the analyzer's internal memory.
Trace data is transferred in either ASCII or block data (REAL) format, depending on the
FORMat[:DATA] setting. If the block data format is used, it is recommended to select EOI as receive
terminator (SYSTem:COMMunicate:GPIB[:SELF]:RTERminator EOI).
Reserved Trace Names
The commands in the TRACe... menu use the following ZVR-compatible parameters to specify traces:
Parameter
Meaning
Used in
CH1DATA, CH2DATA,
CH3DATA, CH4DATA
Active data trace of channels 1 to 4
TRACe:COPY
TRACe[:DATA][:RESPonse][:ALL]?
TRACe[:DATA][:STIMulus][:ALL]?
CALCulate<Chn>:MATH[:EXPRession][:DEFine]
CH1MEM, CH2MEM,
CH3MEM, CH4MEM
Active memory trace associated to the
active data trace CH1DATA, CH2DATA,
CH3DATA, CH4DATA, respectively.
TRACe[:DATA][:RESPonse][:ALL]?
TRACe[:DATA][:STIMulus][:ALL]?
IMPLied
Active data trace, addressed with <Chn>
CALCulate<Chn>:MATH[:EXPRession][:DEFine]
CHMem
Active memory trace assigned to the
IMPlied trace
CALCulate<Chn>:MATH[:EXPRession][:DEFine]
MDATA1, MDATA2,
MDATA3, MDATA4,
MDATA5, MDATA6,
MDATA7, MDATA8
Memory trace named Mem<n>[Trc<m>].
The trace name is unique because <n>
counts all data and memory traces in the
active setup.
TRACe:CLEar
TRACe:COPY
TRACe[:DATA][:RESPonse][:ALL]?
TRACe[:DATA][:STIMulus][:ALL]?
CALCulate<Chn>:MATH[:EXPRession][:DEFine]
TRACe:CLEar MDATA1 | MDATA2 | MDATA3 | MDATA4 | MDATA5 | MDATA6 |
MDATA7 | MDATA8
[Deprecated command, replaced by CALCulate<Ch>:PARameter:DELete]
Deletes one of the memory traces Mem<n>[Trc<m>], where n = 1, ... 8.
Parameters
Identifier for the memory trace; see list of trace names. .
Range [def. unit]
MDATA<n> where <n> = 1 to 8. [–]
*RST value
–
SCPI, Command
Types
Device-specific, no query
Example:
SWE:POIN 20
Create a trace with 20 sweep points, making the created trace the active trace
of channel 1 (omitted optional mnemonic SENSe1).
TRAC:COPY "Mem_Pt20",CH1DATA
Copy the current state of the created trace to a memory trace named
"Mem_Pt20". The memory trace is not displayed.
DISP:WIND:TRAC2:FEED "MEM_PT20"
Display the created memory trace in the active diagram area (diagram area no.
