TRACe:COPY <memory_trc>,<data_trc>
Copies a data trace to a memory trace. The trace to be copied can be specified by two alternative
methods:
 As the active data trace of channels 1 to 4 (CH1DATA, CH2DATA, CH3DATA, CH4DATA). If a
mathematical trace is active, the associated data trace is copied.
 As a trace with a name (string variable)
The created memory trace can be specified as follows:
 As the memory trace named Mem<n>[Trc<m>], where n = 1, ... 8 and Trc<m> is the name of the
copied data trace (MDATA1, MDATA2, MDATA3, MDATA4, MDATA5, MDATA6, MDATA7,
MDATA8)
 As a memory trace with an arbitrary name (string variable)
An existing memory trace with the same name is overwritten.
The copied trace is the data trace which is not modified by any mathematical operations. To copy a
mathematical trace to a memory trace, use TRACe:COPY:MATH. To copy the active trace to the memory
using an automatic memory trace name, use CALCulate<Chn>:MATH:MEMorize.
<memory_trc>
Name of the memory trace.
Range [def. unit]
<memory_trace> is either a string variable (enclosed in single or double quotes)
or one of the following reserved names (no string variables):
MDATA1 | MDATA2 | MDATA3 | MDATA4 | MDATA5 | MDATA6 |
MDATA7 | MDATA8 (only for memory traces Mem<n>[Trc<m>], where n = 1, ...
8; see list of trace names). [–]
*RST value
–
<data_trc>
Name of the data trace
Range [def. unit]
<data_trace> is either a string variable (enclosed in single or double quotes) or
one of the following reserved names (no string variables):
CH1DATA | CH2DATA | CH3DATA | CH4DATA (only for the active data
trace in channels Ch1, Ch2, Ch3, Ch4; see list of trace names). [–]
*RST value
–
SCPI, Command
Types
Confirmed, no query
Example:
*RST; :SWE:POIN 20
Create a trace with 20 sweep points, making the created trace the active trace
of channel 1 (omitted optional mnemonic SENSe1).
TRAC:COPY "Mem_Pt20",CH1DATA
Copy the current state of the created trace to a memory trace named
"Mem_Pt20". The memory trace is not displayed.
DISP:WIND:TRAC2:FEED "MEM_PT20"
Display the created memory trace in the active diagram area (diagram area no.
1).
