tables stored in a file.
The analyzer provides a large number of predefined cal kits but can also import cal kit files and create new
kits:
 A selection of predefined kits is available for all connector types. The parameters of these kits are
displayed in the Add/Modify Standards dialog, however, it is not possible to change or delete the
kits.
 Imported and user-defined kits can be changed in the Calibration Kits dialog and its various sub-
dialogs.
Calibration kits and connector types are global resources; the parameters are stored independently and
are available irrespective of the current setup.
Calibration Types
The analyzer provides a wide range of calibration types for one, two or more ports. The calibration types
differ in the number and types of standards used, the error terms, i.e. the type of systematic errors
corrected and the general accuracy. The following table gives an overview.
Calibration
Type
Standards
Parameters
Error Terms
3)
General
Accuracy
Application
Reflection
Normalization
Open or Short
S
11
(or S
22
, ...)
Reflection
tracking
Low to medium
Reflection measurements on
any port.
Transmission
Normalization
Through
S
12
, S
21
(or S
13
,...)
Transmission
tracking
Medium
Transmission measurements in
any direction and between any
combination of ports.
Full One-Port
Open, Short and Match
1)
S
11
(or S
22
, ...)
Reflection
tracking,
Source match
Directivity
High
Reflection measurements on
any port.
One-Path Two-
Port
Open, Short and Match
1)
(at
source port),
Through
2)
S
11
, S
21
(or S
22
,...)
Reflection
tracking,
Source match,
Directivity,
Transmission
tracking
Medium to high
Unidirectional transmission
measurements in any direction
and between any combination
of ports.
TOSM or UOSM
(2 or more ports)
Open, Short and Match
1)
at
all ports,
Through
2)
between all
directed port pairs
All
Reflection
tracking,
Source match,
Directivity,
Load match,
Transmission
tracking,
High
Reflection and transmission
measurements on DUTs with 2
or more ports; classical 12-term
error correction model.
TOM (2 or more
ports)
Open, Match at all ports,
Through between all
directed port pairs
All
Reflection
tracking,
Source match,
Directivity,
Load match,
Transmission
tracking
High
Reflection and transmission
measurements on DUTs with 2
or more ports.
TRM (2 or more
ports)
Reflect (equal at all ports)
and Match at all ports,
Through between all
directed port pairs
All
Reflection
tracking,
Source match,
Directivity,
Load match,
Transmission
tracking
High
Reflection and transmission
measurements on DUTs with 2
or more ports, especially in test
fixtures.
