SCPI Command Reference
Operating Manual 1145.1084.12 – 30 725
returns the actual trace number).
'<Trc_name>'
Trace name, e.g. 'Ch2Trc2'.
*RST value
–
SCPI, Command
Types
Device-specific, command or query.
Example:
See CONFigure:TRACe<Trc>:CATalog?
CONFigure:TRACe<Trc>:REName '<Old_Tr_Name>', '<New_Tr_Name>'
Assigns a new name to a trace. The trace does not have to be the active trace.
<Trc>
Trace number. This suffix is ignored; the trace is identified via its
<Old_Tr_Name>
'<Old_Tr_Name>'
'<New_Tr_Name>'
Old trace name, e.g. 'Trace 1'
New trace name, e.g. 'Trace 2'
*RST value
–
SCPI, Command
Types
Device-specific, no query.
Example:
See CONFigure:CHANnel<Ch>:TRACe:REName
CONTrol
AUXiliary
CONTrol...
This subsystem provides device-specific commands to control hardware settings related to the rear panel
connectors.
CONTrol:AUXiliary:A[:DATA] <numeric_value> CONTrol:AUXiliary:B[:DATA]
<numeric_value>
Writes a channel-dependent bit pattern to the output ports A or B of the Universal Interface (option R&S
ZVAB-B14). The channel bits are combined with the (static) output bits defined via
CONTrol:HANDler:A|B[:DATA] using a logical "or" operation. The channel bits must be defined while
the channel is active (CONTrol:NSELect <Ch>); the corresponding signals will be in effect while the
channel is measured (dynamic output signals).
To prevent undefined states, it is recommendable to subdivide output pins of ports A and B into two
groups: The first pin group is used as an interface for the static information, the second group provides
channel-dependent output signals, in addition to the channel bits at the USER CONTROL connector (see
