Select real data format.
SYST:COMM:GPIB:RTER EOI
Set the terminator to EOI.
(During a calibration) ... CORR:CDAT? 'REFLTRACK',1,0
Query a system error correction term. The data is transferred in a definite length
block which can be written to a file; the analyzer displays the message
<no_of_bytes> bytes binary data received.
FORMat:DEXPort:SOURce FDATa | SDATa | MDATa
[Deprecated command]
Defines the format for traces retrieved with the ZVR-compatible command
TRACe[:DATA][:RESPonse][:ALL]?
This command is not relevant for results read with the CALCulate:DATA... commands.
Parameters
See list of parameters below.
Range [def. unit]
Depending on the measured parameter and format. The unit is the default unit of
the measured parameter; see CALCulate<Ch>:PARameter:SDEFine.
*RST value
SDATa
SCPI,
Command
Types
Device-specific, command or query.
Example:
See TRACe[:DATA][:RESPonse][:ALL]?
The following parameters are related to trace data (see also Data Flow diagram):
FDATa
Formatted trace data, according to the selected trace format (CALCulate<Chn>:FORMat). 1 value per trace point for
Cartesian diagrams, 2 values for polar diagrams.
SDATa
Unformatted trace data: Real and imaginary part of each measurement point. 2 values per trace point irrespective of the
selected trace format. The trace mathematics is not taken into account. Wave quantities are returned as voltages.
MDATa
Unformatted trace data (see SDATa) after evaluation of the trace mathematics.
HCOPy...
The HCOPy system controls the output of screen information to an external device. Part of the
functionality of this system is included in the File menu.
HCOPy:DESTination <string> | 'MMEM' | 'DEFPRT'
Selects a printer name or file as destination for the screen output.
