R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Measurement Examples
Simple Measurement Tasks
Operating Manual 1145.1084.12 – 30 67
4 Measurement Examples
This chapter provides examples for typical measurement tasks to be performed on the network analyzer.
To make yourself familiar with the instrument, use the simple measurement examples outlined in the
Getting Started chapter. For a systematic explanation of all menus, functions and parameters and
background information refer to the Manual Control reference.
Simple Measurement Tasks
Screen Control
Control of the analyzer's display elements is based on the standard Windows™ functionality. The following
examples show you how to make efficient use of the functions.
To move an active setup window within the available space ...
1. Make sure that the window is not maximized (If necessary, click Window – Cascade to display all
windows with their title bar).
2. Click the icon in the title bar to open the setup control menu.
3. Click Move.
After the pointer changes to the four-headed arrow:
4. Press one of the direction keys (left, right, up, or down arrow key) to move the entire window
without changing its size.
5. Press ENTER or left-click the window when it is at the position you want.
To size the active setup window ...
1. Make sure that the window is not maximized (If necessary, click Window – Cascade to display all
windows with their title bar).
2. Click the icon in the title bar to open the setup control menu.
3. Click Size.
After the pointer changes to the four-headed arrow:
4. Press one of the direction keys (left, right, up, or down arrow key) to move the pointer to the
border you want to move.
5. Press a direction key to move the border.
Press ENTER or left-click the window when it is the size you want.
Display Configuration
The analyzer provides various tools that you can use to customize the diagram areas and control
