SCPI Command Reference
Operating Manual 1145.1084.12 – 30 1077
SCPI,
Command
Types
Device-specific, query only
Example:
SWE:POIN 20
Create a trace with 20 sweep points, making the created trace the active trace of
channel 1 (omitted optional mnemonic SENSe1).
TRAC:STIM? CH1DATA
Query the 20 stimulus values of the created trace. In the default format setting,
the data is returned as a comma-separated list of 10-digit ASCII values.
TRIGger<Ch>...
This subsystem is used to synchronize the analyzer's actions (in particular, the start of a measurement
sequence) with events.
TRIGger<Ch>[:SEQuence]:HOLDoff <delay>
Sets a delay time between the trigger event and the start of the measurement (Trigger Delay).
<Ch>
Channel number. If unspecified the numeric suffix is set to 1.
<delay>
Delay time.
Range [def. unit]
0 s to 13680 s [s]. UP and DOWN increment/decrement the trigger delay in
10 ms steps.
*RST value
0 s
SCPI, Command
Types
Confirmed, command or query
Example:
TRIG:SOUR TIM
Activate internal timer as trigger source.
TRIG:HOLD UP
Set a delay time of 10 ms.
TRIGger<Ch>[:SEQuence]:HOLDoff:GENerator<Gen> <delay>
Defines the trigger delay for a generator port <Gen>. The setting takes effect when a port-specific trigger
delay is selected (TRIGger<Ch>[:SEQuence]:HOLDoff:MODE PSPecific).
<Ch>
Channel number
<Gen>
Generator number
<delay>
Delay time.
Range [def. unit]
0 s to 13680 s [s]. UP and DOWN increment/decrement the trigger delay in
10 ms steps.
