SCPI Command Reference
Operating Manual 1145.1084.12 – 30 1078
*RST value
0 s
SCPI, Command
Types
Device-specific, command or query
Example:
See TRIGger<Ch>[:SEQuence]:HOLDoff:MODE
TRIGger<Ch>[:SEQuence]:HOLDoff:MODE PALL | PSPecific
Qualifies whether the trigger delay is valid for all physical ports (including external generator) or source
port-specific. This setting is available if the triggered measurement sequence is a partial measurement
(TRIGger<Ch>[:SEQuence]:LINK 'PPOint').
<Ch>
Channel number
Parameters
PALL – Same trigger delay at all ports (TRIGger<Ch>[:SEQuence]:HOLDoff)
PSPecific – Port-specific trigger delay defined via
TRIGger<Ch>[:SEQuence]:HOLDoff:PORT<Pt> (for physical analyzer ports) or
TRIGger<Ch>[:SEQuence]:HOLDoff:GENerator<Gen> (for external
generators).
*RST value
PALL
SCPI,
Command
Types
Device-specific, command or query
Example:
TRIG:LINK 'PPOint'
Select partial measurement as triggered measurement sequence.
TRIG:HOLD:MODE PSP
Select port-specific trigger delay.
SYST:COMM:RDEV:GEN1:DEF 'Ext. Gen. 1', 'SME02', 'gpib0', '21'
Configure an R&S SME02 generator as external generator no. 1.
TRIG:HOLD:PORT1 0.001; PORT2 0.002; GEN1 0.003
Define port-specific trigger delays at the analyzer ports 1 and 2 and at the external
generator port 1.
TRIGger<Ch>[:SEQuence]:HOLDoff:PORT<Pt> <delay>
Defines the trigger delay for a physical analyzer port <Pt>. The setting takes effect when a port-specific
trigger delay is selected (TRIGger<Ch>[:SEQuence]:HOLDoff:MODE PSPecific).
<Ch>
Channel number
<Pt>
Analyzer port number
<delay>
Delay time.
Range [def. unit]
0 s to 13680 s [s]. UP and DOWN increment/decrement the trigger delay in
10 ms steps.
*RST value
0 s
