SCPI Command Reference
Operating Manual 1145.1084.12 – 30 1079
SCPI, Command
Types
Device-specific, command or query
Example:
See TRIGger<Ch>[:SEQuence]:HOLDoff:MODE
TRIGger<Ch>[:SEQuence]:LINK 'POINt' | 'SWEep' | 'PPOint' | 'SEGMent'
Selects the Triggered Meas. Sequence. The identifier for the sequence is a string variable.
<Ch>
Channel number
'SWEep' |
Trigger event starts an entire sweep.
'SEGMent' |
Trigger event starts a sweep segment, if segmented frequency sweep is active
(see example below). If another sweep type is active, the trigger event starts an
entire sweep.
'POINt' |
Trigger event starts measurement at the next sweep point.
'PPOint'
Trigger event starts the next partial measurement at the current or at the next
sweep point.
*RST value
'SWEep'
SCPI,
Command
Types
Confirmed, command or query. The query returns the complete string; see
example below.
Example:
SEGM:ADD; :SWE:TYPE SEGM
Select segmented frequency sweep.
TRIG:LINK 'SEGM'
Select a trigger segment as triggered measurement sequence.
TRIG:LINK?
Query the triggered measurement sequence. The response is 'SEGMENT'.
TRIGger<Ch>[:SEQuence]:PULSe REPulse | FEPulse | RESYnc | FESYnc
Selects the trigger source for pulsed measurements (option R&S ZVA-K27) using
- a network analyzer R&S ZVA connected to an Extension Unit R&S ZVAX24 or R&S ZVAX-TRM with
installed pulse modulator option
- a network analyzer R&S ZVT connected to an Extension Unit R&S ZVAX-TRM with installed pulse
modulator option
<Ch>
Channel number
REPulse |
Rising edge of (external) pulse signal (generator 1)
FEPulse |
Falling edge of pulse signal
RESYnc |
Rising edge of (internal) sync signal (generator 2)
FESYnc
Falling edge of sync signal
*RST value
REPulse
SCPI, Command Types
Device-specific, command or query.
Example:
TRIG:PULS REP
